SEALEVEL STATION CATALOG (SSC) |
|
|
|
|
|
| Station catalog metadata [edit] | [station overview] |
|---|
| SSC ID | SSC-acap | | Station Name | Acapulco | | Country | Mexico | | Latitude | 16.8333 | | Longitude | -99.9166 | | DateLastModified | 2015-10-22 19:02:29 |
| Linked codes |
|---|
| Codes | Location | Latitude | Longitude | Sensors | IOC: acap | Acapulco_MX | 16.8333 | -99.9166 | prs, rad |
IOC: acap2 | Acapulco API | 16.8379333 | -99.903 | rad |
IOC: acya | Acapulco Club de Yates | 16.83799 | -99.90298 | flt |
GLOSS: 267 | Acapulco, Gro. | 16.83333 | -99.91666 | Float |
UHSLC: 316 | Acapulco, Gro. | 16.84 | -99.912 | N/A |
PTWC: acap | Acapulco_MX | 16.8408 | -99.8513 | bub, rad |
PTWC: acya | Acapulco_MX | 16.8380 | -99.9030 | flt |
PSMSL: 686 | ACAPULCO | 16.833333 | -99.916667 | N/A |
SONEL_GPS: 2279 | ACAPULCO | 16.83799000 | -99.90298000 | N/A |
SONEL_TG: 2280 | ACAPULCO | 16.83799000 | -99.90298000 | N/A |
| Distributed metadata source: IOC Sea Level Station Monitoring Facility acap |
|---|
| GTS station code | 3540E15A |
| GTS message type | SEPA40 |
| Status | Down |
| Local Contact | Centro de Investigación Científica y de Educación Superior de Ensenada ( Mexico ) |
| Other Contact | University of Hawaii Sea Level Center ( USA ) |
| Other Contact | Centro de Investigación Científica y de Educación Superior de Ensenada ( Mexico ) |
| Connection | GTS message |
| Country | Mexico |
| Sensor 1 | |
| Type of sensor | prs |
| Sampling rate (min) | 1 |
| Sensor 2 | |
| Type of sensor | rad |
| Sampling rate (min) | 1 |
| Distributed metadata source: IOC Sea Level Station Monitoring Facility acap2 |
|---|
| GTS station code | 0100D7CA |
| GTS message type | SOMX10 |
| Status | Operational |
| Local Contact | Universidad Nacional Autónoma de México ( Mexico ) |
| Connection | GTS message |
| Country | Mexico |
| Sensor 1 | |
| Type of sensor | rad |
| Sampling rate (min) | 1 |
| Distributed metadata source: IOC Sea Level Station Monitoring Facility acya |
|---|
| Status | Incorrect data |
| Local Contact | Universidad Nacional Autónoma de México ( Mexico ) |
| Connection | FTP box |
| Country | Mexico |
| Sensor 1 | |
| Type of sensor | flt |
| Sampling rate (min) | 1 |
| Distributed metadata source: GLOSS Station Handbook |
|---|
| Time Zone | 090W, GMT - 6hrs | | Ocean | Pacific | | Operational | Yes | | Responsible country | Mexico | | Additional parameters | Sea temperature, sea density | | Auxiliary benchmarks | Aux#1: It is 4.5ft west of the tide house, 4.75ft north of the seaward face of the pier, 19.9ft east south east of the center of the easternmost iron bollard and 21.5ft east of benchmark #2.
Aux#2: It is 4.75ft north of the seaward face of the pier, 7.6ft south west of the easternmost iron bollard, 25.9ft west of the tide gauge house and 21.5ft west of a line with benchmark 1.
| | Other relevant codes | UHSLC 316 |
| Distributed metadata source: PTWC COMP META file |
| DCP ID | 0100D7CA |
| WMO | SOMX10 |
| Samp Rate | 1 |
| Num# Samp | 11 |
| Unit | M |
| Scale | 1.0000 |
| Xmt Int. | 005 |
| Fst Min. | 0000 |
| HAR | 1 |
| Owner | UNAM |
| Distributed metadata source: UHSLC |
| UHSLC id | 316 |
| SSC id | acap |
| GLOSS id | 267 |
| UHSLC geojson | https://uhslc.soest.hawaii.edu/data/meta.geojson |
| Research quality data version a | 1952-05-02 - 1995-12-31 |
| Research quality data version b | 1999-02-13 - 2005-12-31 |
| Research quality data version c | 2007-05-24 - 2011-04-24 |
| RQ basin | pacific |
| Fast delivery | 2007-05-24 - 2011-04-24 |
| Distributed metadata source: PSMSL |
| Name | ACAPULCO |
| GLOSS id | 267 |
| UHSLC ID | 316 |
| SONEL id | 2279 |
| Is RLR | Y |
| Has RLR Diagram | Y link |
| QC Flag | N |
| Old ID | 830/081 |
| Last Updated | 2015-06-24 |
| Supplier | SERVICIO MAREOGRAFICO NACIONAL, MEXICO |
| Address | Servicio Mareografico Nacional, Instituto de Geofisica, Ciudad Universitaria, Delegacion de Coyoacan, 04510 Mexico D.F., MEXICO |
| Metric Start | 1952 |
| Metric End | 2012 |
| Metric Completeness | 77.2 |
| RLR Start | 1967 |
| RLR End | 2012 |
| RLR Completeness | 69.7 |
| Download metric sea level data. | Use only with extreme caution. |
IOC Sea Level Station Monitoring Facility - realtime graph for 'acap'  IOC Sea Level Station Monitoring Facility - realtime graph for 'acap2'  IOC Sea Level Station Monitoring Facility - realtime graph for 'acya'  PSMSL Annual Mean Sea Level for '686'  PSMSL Monthly Mean Sea Level for '686'
|
|
|
